ARM TABLE

Model No. GTB-7000

OPERATING C-ARM TABLE [ELECTRIC]

Technical Specifications

Electrically operated with cable remote. Having all surgical position Chair, Neuro, Spinal, Flex/ Reflex, Trendelenburg/ reverse Trendelenburg., Lateral, Lithotomy Position. The eccentrically position table column and inter-changeable head and leg section allow optima use of the C-ARM image Intensifier. Movement Controlled by the Actuators to achieve smooth and without any jerks. The Electric System is maintenance free, virtually silent, waterproof, shockproof, demands no force to operate and operates with greater strength and smoother operation. Table is mounted on castors wheels with break. Head and leg sections are interchangeable. Bade and column covers and made of stainless steel for easy cleaning. Rodio Translucent top. Stainless steel rails with clamps accepts all standard accessories. Flex/ Reflex 220 deg.Standard Accessories: Anesthetist Screen, Arm rest with SS top, Padded Lateral Support, Padded Lithotomy Crutches, Padded shoulder support, Rubber mattress.

Model No. GTB-7100

OPERATING C-ARM TABLE [Hydraulic]

Technical Specifications

Hydraulic operated Table. Having all surgical position Chair, Neuro, Spinal, Flex/ Reflex, Trendelenburg/ reverse Trendelenburg., Lateral, Lithotomy Position. The eccentrically position table column and interchangeable head and leg section allow optima use of the C-ARM image Intensifier. Table height adjustment with help of hydraulic and other position with the help of smooth lever handle . Table is mounted on castors wheels with locking device. Head and leg sections are interchangeable. Base and column covers and made of stainless steel for easy cleaning. Rodio Translucent top. Stainless steel rails with clamps accepts all standard accessories. Technical Date: 185 L x 50 W x 75 to 95 Ht. cm. Trendelenburg/ Reverse 35 deg. Lateral tilt 20 deg. (both side) Flex/ Reflex 220 deg. Standard Accessories: Anesthetist Screen, Arm rest with SS top, Padded Lateral Support, Padded Lithotomy Crutches, Padded shoulder support, Rubber mattress.

Model No. GTB-7200

HYDRAULIC OPERATION TABLE [Side End Control]

Technical Specifications

Hydraulic Operation table side end control. Facilitates almost all the purposes and requirements of major/ Minor surgical exercise and procedures. Five sectional table top allows the surgeon to occupy and move to all required & desired positions. Single action Hydraulic Mechanism foot operated. Heavy base stainless steel covered with foot locking Detachable head and leg section. Multi functions lithotomy Position, Trendelenburg Position, Flex/ Reflex Position, Lateral Position, Chair Position. Technical Data. Length of the table top 185, Width of the table top 50 cm, Mini Ht 75 cm Max Ht 95 cm Trendelenburg & Reverse 35 deg. Lateral tilt 20 deg, Flex / Reflex 0 deg / 220 deg. Standard Accessories.: Anesthetic Frame, Shoulder support with pad, lateral Support with pad Arm Board with ss top, Lithotomy strap, mattress.

Model No. GTB-7600

OBSTETRIC LABOUR TABLE [Hydraulic]

Technical Specifications

Hydraulic Obstetric Labour Table. Three section top of stainless steel. Frame made of strong MS steel work. Backrest adjustable on ratchet. The whole top can be tilted to trendelenberg position with the help of lever handle. Conversion is easily and simply performed by slideing the leg section. Single action hydraulic mechanism foot operated. Heavy base stainless steel covered with foot locking. The table is complete with the following accessories. Chrome plated lithotomy rod, hand grip, saline rod, side & head railing, stainless steel bowl.
